YT35V00004F1 Kobelco Solenoid Valve SK60 Sk60-5 SK70
Product name: Kobelco Solenoid Valve
Part No: YT35V00004F1 YT35V00005F1 YT35V00006F1
Model Number:For SK60 Sk60-5 SK70 SK80
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
| COGENG Part Number |
KVL-35F04S |
KVL-35F05S |
KVL-35F06S |
| Replaces OEM Part |
YT35V00004F1 |
YT35V00005F1 |
YT35V00006F1 |
| Compatible Models |
SK60, SK60-5, SK70 |
SK60, SK60-5, SK70 |
SK60, SK60-5, SK70 |
| Primary Function |
Swing Control |
Travel Control |
Auxiliary Functions |
| Identification |
Blue Stripe |
Green Stripe |
Yellow Stripe |
| Electrical Specifications |
|
|
|
| - Operating Voltage |
12V DC ±10% |
12V DC ±10% |
12V DC ±10% |
| - Current Consumption |
0.8A @ 20°C |
1.0A @ 20°C |
0.9A @ 20°C |
| - Response Time |
< 20ms |
< 25ms |
< 22ms |
| - Insulation Class |
Class H |
Class H |
Class H |
| Hydraulic Performance |
|
|
|
| - Maximum Pressure |
250 bar |
250 bar |
250 bar |
| - Flow Capacity |
15 L/min |
18 L/min |
16 L/min |
| - Pressure Drop |
< 2.0 bar @ 10 L/min |
< 2.0 bar @ 10 L/min |
< 2.0 bar @ 10 L/min |
Application Guide for Mini Excavators
-
KVL-35F04S (Blue Stripe): Primary application in swing motor control circuit – optimized for smooth 180° rotation control
-
KVL-35F05S (Green Stripe): Travel motor control functions – provides precise control for both track motors simultaneously
-
KVL-35F06S (Yellow Stripe): Auxiliary hydraulic functions – controls auxiliary circuits for hydraulic attachments and accessories
Service Recommendation: For mini excavators operating in rental or high-utilization applications, consider replacing the complete valve set to ensure balanced hydraulic performance and prevent future downtime. The compact design ensures easy installation even in the confined spaces typical of mini excavator hydraulic systems.
Decompose pictures
| Physical Specifications |
|
|
|
| - Housing Material |
Corrosion-Resistant Brass |
Corrosion-Resistant Brass |
Corrosion-Resistant Brass |
| - Overall Length |
85 mm |
85 mm |
85 mm |
| - Connector Type |
Compact 4-pin |
Compact 4-pin |
Compact 4-pin |
| - Weight |
0.45 kg |
0.48 kg |
0.46 kg |
Here are some additional details about
The Kobelco Solenoid Valve is a hydraulic valve that controls the flow of hydraulic fluid in a hydraulic system. It is used in a variety of applications, including construction equipment, industrial machinery, and agricultural equipment.
Features:
High-pressure rating
Long service life
Reliable operation
Compact design
Easy to install and maintain
Applications:
Construction equipment
Industrial machinery
Agricultural equipment
Other hydraulic systems
Specifications:
Pressure rating: Up to 35 MPa (5000 psi)
Flow rate: Up to 100 L/min (26.4 GPM)
Voltage: 12 V or 24 V
Duty cycle: Intermittent
Installation:
The Kobelco Solenoid Valve can be installed in any position. It is important to ensure that the valve is properly sized for the application and that it is installed in a location that is free from vibration and excessive heat.
Maintenance:
The Kobelco Solenoid Valve requires minimal maintenance. It is important to inspect the valve regularly for leaks and to replace any worn or damaged parts.
Parts list
| NO |
Number |
Name |
Qty |
| 1 |
YT35V00002F1 |
VALVE ASSY,SOLENOID |
|
| 2 |
YT35V00004F1 |
VALVE ASSY,SOLENOID |
1 |
| 3 |
YT35V00005F1 |
VALVE ASSY,SOLENOID |
3 |
| 4 |
YT35V00006F1 |
VALVE ASSY,SOLENOID |
2 |
| 5 |
|
PLUG,Remarks:' |
10 |
| 6 |
YT35V00002S006 |
CAPSCREW |
12 |
| 7 |
|
NAME PLATE.Remarks: |
1 |
Installation decomposition diagram
