| Parameter | Specification |
|---|---|
| COGENG Part Number | SW-KOB-00002P1 |
| Replaces OEM Number | YN50S00002P1 |
| Product Category | Electrical Switch Assembly |
| Voltage Rating | 24V DC Standard |
| Current Capacity | 10A Resistive Load |
| Contact Material | Silver-Cadmium Oxide Alloy |
| Housing Material | Glass-Filled PBT |
| Protection Rating | IP67 (Dust Tight/Water Immersion) |
| Temperature Range | -40°C to +85°C |
| Connector Type | OEM Waterproof Connector |
| Mechanical Life | 150,000 minimum cycles |
| Certification | ISO 9001 |
| NO | Number | Name | Qty |
| 1 | 8240-06-1111 | BOX | 1 |
| 2 | 8260-06-1110 | PANEL | 1 |
| 3 | 8240-06-1151 | • PACKING | 1 |
| 4 | 8240-06-1260 | • PACKING | 1 |
| 5 | 8240-06-1270 | • PACKING | 4 |
| 6 | 8240-06-1280 | • PACKING | 1 |
| 7 | 8240-06-1290 | • PACKING | 1 |
| 8 | 8247-06-7470 | • HINGE | 2 |
| 9 | YN50S00002P1 | Switch Parts | 1 |
| 10 | 8240-06-1190 | • PLATE | 1 |
| 11 | 01224-40412 | SCREW | 6 |
| 12 | 01023-20625 | SCREW | 6 |
| 13 | 8240-06-1133 | COVER | 1 |
| 14 | 8240-06-1160 | • SEAL | 1 |
| 15 | 8240-06-1170 | • SEAL | 1 |
| 16 | 8240-06-1180 | • SEAL | 1 |
| 17 | 195-54-78790 | SNAP RING | 2 |
| 18 | 205-60-71220 | LOCK ASS'Y | 1 |
| 19 | 8298-06-1330 | CATCH | 1 |
| 20 | 01224-40408 | SCREW | 2 |
| 21 | 01224-40416 | SCREW | 2 |
| 22 | 205-54-66530 | 1 | |
| 23 | 01023-10412 | SCREW | 4 |
| 24 | 8240-06-1490 | SHEET | 1 |
| 25 | 8240-06-1970 | PLATE | 1 |
| 26 | 01010-80616 | BOLT | 3 |
| 27 | 01643-30623 | WASHER | 3 |
| 28 | 8240-06-1310 | PLATE | 1 |
| 29 | 8255-06-4810 | BOLT | 4 |
| 30 | 8295-06-2191 | BAR | 1 |
| 31 | 04052-10833 | PIN | 1 |
| 32 | 8221-06-1480 | SWITCH | 3 |
| 8221-06-1670 | • CAP¤ GREEN | 1 | |
| 33 | 8221-06-1520 | SWITCH | 3 |
| 8221-06-1680 | • CAP¤ BLACK | 1 | |
| 34 | 8221-06-1470 | SWITCH | 1 |
| 8221-06-1660 | • CAP¤ RED | 1 | |
| 35 | 8221-06-1530 | SWITCH | 3 |
| 8221-06-1650 | • CAP¤ YELLOW | 1 | |
| 36 | YN50S00029F1 | Switch Parts | 1 |
| 37 | 7825-30-1301 | DIAL | 1 |
| 38 | 01252-70410 | BOLT | 2 |
| 39 | 01601-20410 | WASHER | 2 |
| 40 | 7824-84-2810 | SWITCH | 1 |
| 41 | 14X-06-12160 | SWITCH | 1 |
| 42 | 09415-01610 | CAP | 5 |
| 43 | 09415-01008 | CAP | 2 |
Disconnect negative battery terminal
Identify and access existing switch location
Document wiring configuration with photos
Disconnect electrical connectors carefully
Remove mounting hardware and old switch
Install new COGENG switch assembly
Reconnect electrical connectors securely
Verify proper mounting and alignment
Reconnect power and test functionality
Conduct operational verification tests
