| Specification Category | Technical Details |
|---|---|
| COGENG Part Number | KVL-35Y1 |
| Replaces OEM Part | Kobelco YB35V00006F1 |
| Identification Marking | Yellow Dot |
| Compatible Models | SK200SR, SK210LC-6E, ED190LC-6E |
| Application | Main Control Valve - Specific Function Circuit |
| Electrical Specifications | |
| - Operating Voltage | 24V DC ±10% |
| - Power Consumption | 28W nominal |
| - Response Time | < 25ms |
| - Insulation Resistance | > 100MΩ @ 500VDC |
| Hydraulic Performance | |
| - Maximum Pressure | 380 bar (5,511 psi) |
| - Operating Pressure Range | 20-350 bar |
| - Flow Rating | 45 L/min @ 35 bar ΔP |
| - Leakage Rate | < 5 drops/minute @ max pressure |
| Environmental Specifications | |
| - Temperature Range | -40°C to +125°C |
| - Protection Rating | IP67 |
| - Vibration Resistance | 10G (5-2000 Hz) |
| NO | Number | Name | Qty |
| YN35V00039F | SOLENOID VALVE ASSY | ||
| 101 | YN35V00039510 | BODY | 1 |
| 151 | 2436U1165S152 | PLUG | 1 |
| 171 | YX35V00002S171 | SCREW M05x0.8x12mn | 16 |
| 601 | YB35V00005F1 | VALVE SOLENOID | 4 |
| 701 | YT35V00013F1 | VALVE SOLENOID | 3 |
| 702 | YB35V00006F1 | VALVE SOLENOID | 1 |
| 901 | YA35V00001S901 | PLATE NAME | 1 |
| Mechanical Specifications | |
| - Housing Material | Anodized Aluminum Alloy |
| - Connector Type | Weatherproof 4-pin |
| - Weight | 0.72 kg (1.59 lbs) |
| Quality Standards | |
| - Manufacturing Standard | IATF 16949:2016 |
| - Performance Testing | ISO 6403 |
| - Service Life | > 3 million cycles |
| Warranty | 3,000 operating hours / 24 months |
