| Parameter | Specification |
|---|---|
| COGENG Part Number | SV-VOL-KIT-24V |
| Replaces OEM Numbers | VOE1307048 VOE13949371 VOE8158342 VOE1589338 VOE1598753 |
| Voltage Rating | 24V DC (OEM Standard) |
| Maximum Pressure | 350 Bar (5,075 PSI) |
| Operating Temperature | -40°C to +120°C |
| Body Material | Carbon Steel with Anti-Corrosion Coating |
| Seal Material | Hydrogenated Nitrile (HNBR) |
| Electrical Connection | OEM-Compatible Weatherproof Connectors |
| Fluid Compatibility | Mineral-based Hydraulic Oils (ISO VG 46) |
| Quality Standard | ISO 9001:2015 Certified |
| NO | Number | Name | Qty |
| 1 | VOE1589338 | Solenoid Valve | 1 |
| VOE1598753 | Solenoid Valve | 1 | |
| VOE1307048 | Solenoid Valve | 1 | |
| VOE13949371 | Solenoid Valve | 1 | |
| VOE8158342 | Solenoid Valve | 1 | |
| 2 | VOE960629 | Plug | 1 |
| 3 | VOE945916 | Elbow nipple | 2 |
| 4 | VOE945893 | Hexagon nut | 2 |
| 5 | VOE13945901 | Nipple | 1 |
| 6 | VOE13954378 | Nipple | 1 |
| 7 | VOE13947282 | Gasket | 3 |
| VOE13947282 | Gasket | 3 | |
| 8 | VOE13945460 | Plastic pipe | REQ |
| 9 | VOE13945460 | Plastic pipe | REQ |
| 10 | VOE13946934 | Screw | 2 |
| 11 | VOE4821292 | Cable tie | 6 |
| 12 | VOE945897 | Gasket | 1 |
| 13 | VOE954356 | Fitting nut | 4 |
| 14 | VOE954364 | Ferrule | 4 |
| 15 | VOE944717 | Sleeve | 4 |
Always depressurize hydraulic system before installation
Use provided replacement seals for optimal performance
Recommended torque: 15-20 Nm for mounting bolts
Perform system diagnostic reset after installation
Verify proper electrical connections before operation
Warranty: 24-month limited warranty
Availability: Global shipping with technical support in multiple languages
Q: What Volvo models use the VOE1307048 and VOE13949371 solenoid valve kit?
A: The COGENG OEM-compatible solenoid valve kit is a direct replacement for Volvo part numbers VOE1307048 and VOE13949371, designed for use across various Volvo construction machinery models where these solenoid valve part numbers are specified. Common applications include hydraulic control systems on Volvo excavators, wheel loaders, and other heavy equipment. Always verify the part number against your machine's parts manual or the original solenoid valve's identification label to confirm exact compatibility before ordering.
Q: What are the symptoms of a failing solenoid valve on Volvo construction equipment?
A: Common symptoms include the controlled hydraulic function failing to operate or operating intermittently, slow or delayed response when the function is activated, the solenoid clicking but no hydraulic movement, the solenoid coil overheating, blown fuses related to the solenoid circuit, or the machine being restricted to a single operating mode. A faulty solenoid valve can also register diagnostic trouble codes on the Volvo machine control system.
Q: What is the relationship between part numbers VOE1307048 and VOE13949371?
A: These two part numbers may represent the same solenoid valve with one being a superseded or updated part number from Volvo, or they may represent similar solenoid valves used in different applications across Volvo equipment. The COGENG kit is designed to be compatible with both part number references. Please verify which specific part number your machine requires before ordering.
